Description
Model: JC-8000ET-4AC-R2
Name：hf blister welding machine high frequency light flash clamshell packaging equipment
Brief description：
hf blister welding machine a type of pneumatic rf welding machine for Led Flash light Lenser pvc plastic clam shell blister packing.This is a standard model of JCwelder high frequency welding machine series.
Applications:
hf blister welding machine high frequency Led Llashlight Lenser,light flas clamshell packaging machine. expert pvc blister welding machine for daliy necessarily clamshell lip balm,lip care stick,Lip Moisturize,makeup,AA battery,lipstick and hardware clamshell paperboard packaging. radio frequency pvc clam shell welding machine. Wide used for making handbag, pencil box/id card sleeve ,small spraying toys, leather products, carpet, plastic inflatable products clothes and shoes embossing tool, trademark, box, air tool, carpet, package bag, heat water bag, medical treatment articles, stationary, photo album, physical good, pvc folding box, glass box, garment logo welding and shoe upper and so on.
Features:
- Using high Q value vibration tube for stable and reliable output
- With round working table which rotate automatically/ by control button
- With 3~6 working positions on the table for choose which work alternatively
- pneumatic pressing system, max pressure can up to 350KG
- Heated electrode welding horn holding plate for good plastic welding result
- HF generator at a stabilized frequency of 27.12MHz. + -0.6%.
- With 5557 anti-spark device, for protecting machine and welding mould from over current
- Feeding voltage 1/3phases,220V/380V, 50/60Hz + ground or customized
- Production speed: 3000~4000 cycles per days( 8 working hours as usual).
- The program is pre-setting up, the circuit can be counter-action of two circuits
- With high precision temperature controlling can assure the coherence of welding
Specifications：
welding mold & samples
Working video of machines:
We already upload working video of this series machine to our YouTube video center, please kindly check the links
Mail us to get more details and latest quotation of machine
Similar design of hf blister welding machine for reference：
- Standard design rotation high frequency welding machine model：JC-8KWET
- upgrade design rotation hf blister welding machine with robot model JC-8KWET-R1
- Brief design hand push high frequency pvc blister welder：JC-5000s
- Basic design sliding table hf pvc clamshell welding machine：JC-5000AT
Our Services
- Pre -sales service
- —1) Show right&clear function and detail of our machines in our website. Get Inquiry& consulting of machine directly.
- —2) Recommend the most suitable hf blister welding machine that client need by Samples or mails.
- —3) Client could send some material to our factory to make free welding test and get expert suggestion.
- After-sales service
- —1) Training how to install the hf blister welding machine.1-2days machine training free in our factory.
- —2) Engineers available to service machine overseas if client need and confirm in the contract
- —3) Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(expect for man made).
- —4) we will provide 24hours 7days/per week online technology support service.
Packaging & Delivery—Pallet with plywood or ply wooden case & sea delivery
